Siemens | 6ES7522-1BH10-0AA0 | Digital Output Module | 4 AMP

General Information:

• Product Name: SIMATIC S7-1500, Digital Output Module
• Model Number: 6ES7522-1BH10-0AA0

Specifications:

• Number of Digital Outputs: 16
• Output Type: 24V DC
• Output Current per Channel: 0.5 A

Technical Data:

• Output Delay:
  • Turn-on time: 100 µs
  • Turn-off time: 100 µs
• Load Type: Resistive and inductive loads
• Output Voltage Range: 20.4 to 28.8 V DC
• Total Current (Module): 8 A
• Short-Circuit Protection: Yes (per channel)
• Diagnostics: Yes (diagnostics for wire break, short-circuit, and module status)

Environmental Conditions:

• Operating Temperature Range: -25 to 60 °C (-13 to 140 °F)
• Storage Temperature Range: -40 to 70 °C (-40 to 158 °F)
