Panasonic MDDDT5540 Servo Drive

Specification

Brand:Panasonic
Model Number: MDDDT5540
Product Type: AC Servo Drive
Series: MINAS A4 Series
Input Voltage: 3-Phase 200-230V AC
Output Power: 5.0 kW
Rated Current: 19.5 A
Control Mode: Position, Speed, Torque Control
Interface: RS-232C, RS-485, or analog input for control
Encoder Feedback: Incremental or Absolute Encoder
Motor Compatibility: Works with Panasonic MINAS A4 series servo motors
Frequency Response: 1 kHz
Overload Capacity: 300% for 3 seconds
Operating Temperature: 0°C to 55°C (32°F to 131°F)
Protection Features: Overcurrent, Overvoltage, Undervoltage, Overheating, Motor Overload Protection
