KS-HE-024-1 | TE Connectivity | 24 VDC | 640 Ohms |1.5 W

General Information:

• Part Number: KS-HE-024-1
• Type: Electromechanical Relay

Electrical Specifications:

• Coil Voltage: 24 V DC
• Contact Rating:
  • Voltage: 250 V AC / 30 V DC
  • Current: 10 A
• Coil Resistance: 640 Ohms
• Power Consumption: 1.5 W

Mechanical Specifications:

• Dimensions:
  • Length: 28 mm
  • Width: 12.7 mm
  • Height: 15 mm
• Weight: 25 grams
• Mounting Type: PCB mount

Performance Specifications:

• Contact Material: Silver Alloy
• Operate Time: 10 ms
• Release Time: 5 ms
• Electrical Life: 100,000 operations
• Mechanical Life: 10,000,000 operations

Environmental Specifications:

• Operating Temperature Range: -40°C to 85°C
• Storage Temperature Range: -40°C to 125°C
• Humidity: 5% to 85% RH
