IME12-0BPSZC0S | SICK | 30 VDC | 10 mA

Model: IME08-02BPSZCOS

Supply Voltage: 10 … 30 V DC

Current Consumption (Without Load): 10 mA

Continuous Current I_a: 200 mA

Voltage Drop: 2 V

Switching Output: PNP

Output Function: Normally Open

Switching Frequency: 4000 Hz

Connection Type: M12 Connector, 4 Pin

Enclosure Rating: IP67

Ambient Operating Temperature: -25 … 75°C

Housing Material: Metal, Nickel-Plated Brass;

Sensing Face Material: Plastic (PA 66)

Mounting: Flush Mountable

Housing: Cylindrical Thread

Thread Size: M8 x 1

Diameter: 8 mm

Housing, Thread Length: 52, 28 mm
