Allen Bradley 140-MN-0400 Circuit Breaker

Specification

• Product Type: Motor Protection Circuit Breaker
• Brand: Allen Bradley
• Model: 140-MN-0400
• Series: 140M
• Rated Operating Voltage (Ue): 690V AC
• Rated Insulation Voltage (Ui): 690V AC
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Rated Current (In): 4.0 A
• Adjustable Current Range: 2.5 – 4.0 A
• Breaking Capacity:
  • 50 kA at 400V AC
  • 25 kA at 690V AC
• Utilization Category: AC-3
• Frequency: 50/60 Hz
• Thermal Overload Protection: Adjustable
• Magnetic Short-Circuit Protection: Fixed
• Protection: IP20 (front side)
• Mounting: DIN Rail or Screw Mounting
• Trip Class: 10A
• Operating Temperature: -25°C to +55°C
• Certifications: CE, UL, CSA, CCC
