800FMMT44 | ALLEN BRADLEY |10 AMPS | 690 VAC

• 800FX20D
• CONTACT BLOCK
• DOUBLE CIRCUIT
• 10 AMPS
• 690 VAC
• 2 NO
• 22.5MM PB
• NO LATCH
• SCREW

Specifications

Additional Specifications

• Operator Type: Mushroom head, twist to release
• Operator Size: 40 mm
• Operator Material: Metal
• Operator Color: Red
• Switching Function: Latching
• Contact Block Thermal Current Rating: 10 A
• Mechanical Life: 300,000 cycles for operator, 10 million cycles for contact block
• Enclosure Compatibility: IP66, Type 4/13 (Round metal operator)
• Unlocking Method: Turn-release
• Hole Diameter: 22.5 mm
• Vibration: 10 G
• Shock: 100 G
• Operating Temperature: -25 C to 60 C
• Storage Temperature: -40 C to 85 C
• Humidity: 95% RH from 2560 C

Disclaimer: Ribhu International is not an affiliate nor an authorized surplus dealer for the product’s manufacturer. The product can be from an earlier series or have date codes than what is offered directly from the manufacturer or authorized retailers. Ribhu International is not an authorized distributor of this product, so the guarantee from the original manufacturer is invalid. Although a lot of Allen-Bradley PLC products come with firmware pre-installed, Ribhu International does not guarantee that a PLC product will contain firmware or not, or if it does, if the firmware is the version you want for your application.
