Specifications
- Number of Main Contacts (NO): 3
- Number of Auxiliary Contacts (NO): 1
- Vibration Resistance: Compliant with IEC 60068-2
- Shock Resistance: Compliant with IEC 60068-2
- Altitude, Max: 2000 meters per IEC 60947-4
- Mechanical Lifespan: 15,000,000 operations
- Switching Frequency, Max: 250 operations per hour
- Conductor Cross Section: 1 to 2.5 mm² (main contact), 1 to 4 mm² (auxiliary contact)
- Protection Class: IP2X
- Coil Voltage: 24V DC (17-30V)
- Rated Operational Current (Ie): 5A
- Rated Insulation Voltage (Ui): 690V (IEC), 600V (UL/CSA)
- Rated Impulse Withstand Voltage (Uimp): 6 kV
- Switching of Motor Load: 6A at 400V, AC-7b
