Specification
Brand: Yokogawa
Model: F3WD64-3P
Module Type: Digital Input/Output Module
Number of Channels:32 Digital & Inputs Output
Input Voltage Range: 24 V DC
Input Signal Type: Sink/Source Type
Output Voltage: 24 V DC
Output Current: Max 0.5 A per channel
Input Delay: 10 ms
Output Delay: 0.5 ms
Connector Type: Terminal Block
Isolation: Opto-Isolated
Mounting Type: DIN Rail Mountable
Power Supply Voltage: 5 V DC
Power Consumption: Typically around 6 W
Operating Temperature: 0 to 55°C
Storage Temperature: -20 to 70°C
Humidity: 5% to 95% RH (non-condensing)
Dimensions: Typically 100 x 28 x 90 mm (H x W x D)
Weight: Approx. 150 grams
