Specification
Brand:Schneider Electric
Product Type: Miniature Circuit Breaker (MCB)
Series: Acti9 iC60
Number of Poles: 3P
Rated Current: 25 A
Breaking Capacity:10 kA at 230/400 V AC & 20 kA at 230/400 V AC (with Vigi iC60)
Curve Type: C-Curve
Rated Voltage: 230/400 V AC
Frequency: 50/60 Hz
Tripping Mechanism: Thermal-magnetic
Standards Compliance: IEC/EN 60898-1, IEC/EN 60947-2
Protection Type: Overload and short circuit protection
Mounting: DIN rail
Ambient Operating Temperature: -30 to +70 °C
Height: 85 mm
Width: 54 mm (18 mm per pole)
Depth: 73.5 mm
Top/bottom terminals: tunnel terminals for 1 to 25 mm² cables (flexible or rigid)
Weight: 0.45 kg
