D-82178 | AMI-Elektronik | 10-30 VDC | IP64

Original price was: ₹25,500.00.Current price is: ₹24,000.00.

Weight 0.05 kg
Brands

AMI-ELEKTRONIK
Conditions

New
Compare
Add to wishlist
Description



  • Type: Incremental Rotary Encoder
  • Technology: Optical
  • Construction: Solid Shaft
  • Output Signal: Analog, Digital, RS-422, Sine Wave
  • Material: Aluminum Housing
  • Supply Voltage: 10-30V DC
  • Pulse Rate: Up to 10,000 pulses per revolution (ppr)
  • Current Consumption: Max 120 mA (unloaded)
  • Shaft Load:
    • Axial: 10 N
    • Radial: 20 N
  • Rotating Speed: Max 10,000 RPM
  • Protection Level: IP64 (Optional IP67 for enhanced protection)
  • Operating Temperature Range: 0C to +80C
  • Housing Diameter: 58 mm
  • Shaft Diameter: 10 mm, Stainless Steel
  • Vibration Resistance: 10 g (20 – 2,000 Hz)
  • Shock Resistance: 100 g (11 ms)



Shipping & Delivery

MAECENAS IACULIS

Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.

ADIPISCING CONVALLIS BULUM

  • Vestibulum penatibus nunc dui adipiscing convallis bulum parturient suspendisse.
  • Abitur parturient praesent lectus quam a natoque adipiscing a vestibulum hendre.
  • Diam parturient dictumst parturient scelerisque nibh lectus.

Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.

SKU: RI00980 Category:
